Series 2600 System SourceMeters Reference Manual Factory Scripts 13-27
Return to Section 13 topics 2600S-901-01 Rev. A / May 2006
Output
Data:
Pulsed current measurements are stored in the reading buffer specified by
the buffer input argument.
Example:
ConfigPulseVMeasureISweepLog(smub, 0, 1, 10, 1, 10e-3,
20e-3, 10, smub.nvbuffer1, 6)
Setup a pulsed log sweep that will use SourceMeter channel B. The pulsed
sweep will start at 1V, end at 10V, and return to a 0V bias level between
pulses. Each pulsed-step will be on for 10msec and then at the bias level for
20msec. The current limit will be 1A during the entire pulsed-sweep. The
pulse train will be comprised of 10 pulsed-steps and the pulse train will be
assigned a tag index of 6.
See Also: InitiatePulseTest, InitiatePulseTestDual
