Series 2600 System SourceMeters Reference Manual Factory Scripts 13-31
Return to Section 13 topics 2600S-901-01 Rev. A / May 2006
Example(s):
(continued)
Configure SourceMeter channels A to generate a pulse train. If no errors are
encountered, initiate the pulse train. Channel A will pulse voltage from a bias
level of 0V to pulse level of 5V. The pulse level will be present for 2 msec and
the bias level for 200 msec, with a 1A limit setting. A total of 10 pulses will be
generated and the measurement data will be stored in smua.nvbuffer1.
This pulse train will be assigned to tag = 1.
See Also: ConfigPulseIMeasureV, ConfigPulseVMeasureI,
ConfigPulseIMeasureVSweepLin,
ConfigPulseVMeasureISweepLin,
ConfigPulseIMeasureVSweepLog,
ConfigPulseVMeasureISweepLog
