C-2 Common Commands Series 2600 System SourceMeters Reference Manual
2600S-901-01 Rev. A / May 2006 Return to Appendix C topics
Introduction
This appendix includes information on common commands and their script
command equivalents.
Common commands
Command summary
Common commands supported by the Series 2600 SourceMeter are summarized
in
Table C-1. Although commands are shown in upper-case, common commands
are not case sensitive, and either upper or lower case can be used. Note that
although these commands are essentially the same as those defined by the IEEE-
488.2 standard, the Series 2600 does not strictly adhere to that standard.
Table C-1
Common commands
Mnemonic Name Description
*CLS Clear status Clears all event registers and Error Queue.
1
*ESE <mask> Event enable command Program the Standard Event Enable Register.
1
*ESE? Event enable query Read the Standard Event Enable Register.
1
*ESR? Event status register query Read/clear the Standard Event Enable Register.
1
*IDN? Identification query Returns the manufacturer, model number, serial
number, and firmware revision levels of the unit.
*OPC Operation complete command Set the Operation Complete bit in the Standard
Event Register after all pending commands have
completed.
*OPC? Operation complete query Places an ASCII “1” into the Output Queue when
all selected device operations have completed.
*RST Reset command Returns the SourceMeter to default conditions.
*SRE <mask> Service request enable
command
Programs the Service Request Enable Register.
1
*SRE? Service request enable query Reads the Service Request Enable Register.
1
*STB? Status byte query Reads the Status Byte Register.
1
*TRG Trigger command Sends a remote trigger to the SourceMeter.
*TST? Self-test query Returns a 0.
*WAI Wait-to-continue command Waits until all previous commands have
completed.
1. Status commands are covered in Appendix D.
