Kelly 45 - Wiring diagram; Mounting swivels

6968
Wiring diagram
3 1 6 5
D C B A
D C B A
89194 Plug
85940 Lamp
85940 Lamp
LED110RM Light
LED110RM Light
5 Core 12.5m
2 Core 6.6m
2 Core 4.3m
5 Core 6.6m
2 Core 1.3m
2 Core 0.4m
Assembly Update 005
Mounting Swivels Page 1 of 1
KEFM77-Assembly Update Revision A 01/03/2011
Fixed housing end of swivel
should always face forward
Mounting like this prevents
dirt getting forced into the
seals of the swivel increasing
longevity of the swivel
Rotating seal end of swivel
should always face rearward
Swivels attached to the
leading ends of the chains
should have the rotating seal
end attached to the chain
like shown
Swivels attached to the
trailing ends of the chains
should have the fixed
housing end attached to the
chain like shown
For Example
Fixed housing end of swivel
should always face forward
Rotating seal end of swivel
should always face rearward
For example
Swivels attached to the leading
ends of the chains should have
the rotating seal end attached
to the chain, as shown
Swivels attached to the trailing
ends of the chains should have the
xed housing end attached to the
chain, as shown
Mounting like this prevents dirt
getting forced into the seals of the
swivel increasing longevity of the
swivel
Mounting swivels
