Section 2
Parts
CAUTION
Before cutting straps attach slings or chains and take the
weight of the frames to avoid them slipping or falling
and causing injury.
CAUTION
Wear eye and hand protection when cutting straps.
Sharp edges are exposed as straps separate and may
cause injury.
CAUTION
To avoid falling or moving components, before cutting
straps attach slings or chains to individual pieces and
only cut the straps holding the piece to be lifted
.
• Remove boxes from rear of container one at a time
using a forklift truck. Each box weighs approximately
2600 lbs (1200 kg)
• Identify parts for each machine by serial no. or
description and separate. Open parts box and check
that all parts are accounted for against checklist
• Cut straps holding bundles and separate parts and
place in assembly area
• Once all parts have been identied machines are ready
for assembly
• Read assembly instructions before proceeding.
Lift under centre frame only
Do not lift under packing frame
!
!
!
