2.3 Specifications
•
Frequency of Operation: 10KHz or 20kHz.
•
Standby Battery Current: < 0.5mA.
•
5V or 12V Sensor Supply Current: 40mA.
•
Controller supply voltage range: PWR, 8V to 30V for pin7 and pin6 which must be isolated
from main battery pack B+/B-.
•
Supply Current, PWR, 30mA Typical.
•
Configurable battery voltage range, B+. Max operating range: 18V to 1.25*Nominal Voltage.
•
Standard Throttle Input: 0-5 Volts(3-wire resistive pot), 1-4 Volts(hall active throttle).
•
Throttle Input: 0-5 Volts. Can use 3-wire pot to produce 0-5V signal.
•
•
Full Power Operating Temperature Range: 0
℃
to 70
℃
(MOSFET temperature).
•
Operating Temperature Range: -40
℃
to 100
℃
(MOSFET temperature).
•
Max Battery Current :Configurable.
2.4 Name Regulation
The name regulation of Kelly KLS motor controllers
:
KLS 8080I/IPS
KLS:Kelly BLDC motor controller based on sinusoidal waveform.KLS8080I is supposed
to work with brushless motor with three hall sensors while KLS8080IPS can work with
Sin/Cosin speed sensors.There are +5V,Sin,Cosin and GND I/O ports for brushless motor
with Sin/Cosin speed sensors.
I:KLS8080I is designed by opto-isolated technology.We specify 8-30V for power supply
which must be isolated from main battery pack B+/B-.
Kelly KLS8080I/IPS Sinusoidal Brushless Motor Controller
Model
60 seconds
Current(Amp)
Continuous
Current(Amp)
Voltage(Volt)
KLS72501-8080I/IPS 500 200 24-72
KLS72601-8080I/IPS 600 240 24-72
KLS72701-8080I/IPS 700 280 24-72
Model
30 seconds
Current(Amp)
Continuous
Current(Amp)
Voltage(Volt)
KLS96501-8080I/IPS 500 200 24-96
KLS96601-8080I/IPS 600 240 24-96
KLS12201-8080I/IPS 200 80 24-120
KLS12301-8080I/IPS 300 120 24-120
KLS14201-8080I/IPS 200 80 24-144
KLS14301-8080I/IPS 300 120 24-144
KLS14401-8080I/IPS 400 160 24-144
