Connect the Dell R-Series
Copyright © 2002 - 2016 KEMP Technologies, Inc. All Rights Reserved. 11
Figure 2-10: Network Interface screen
14. In the Network Interface 0 screen, enter the IP address of the eth0 interface, the
network facing interface of the LoadMaster, in the Interface Address field.
15. Click the Set Address button.
16. Click the eth1 menu option within the Interfaces section.
17. In the Network Interface 1 screen, enter the IP address of the eth1 interface, the farm-
side interface of the LoadMaster, in the Interface Address field.
18. Click the Set Address button.
This interface is optional, depending on the network configuration.
19. Click on the Local DNS Configuration > Hostname Configuration menu option.
Figure 2-11: Set Hostname screen
20. In the Hostname configuration screen, enter the hostname into the Current Hostname
input field.
21. Click the Set Hostname button.
22. Select the Local DNS Configuration > DNS Configuration menu option.
