Kemp LoadMaster User Manual

Dell R-Series
Connect the Dell R-Series
Copyright © 2002 - 2016 KEMP Technologies, Inc. All Rights Reserved. 7
Figure 2-3: Select the target disk
5. Select the target disk for installation and press OK.
Figure 2-4: Delete existing partition(s)
6. Select delete existing partition(s) and press OK.
Figure 2-5: Start installation
7. Select start installation and press OK.
8. Press OK. The installation should complete successfully.
PXE and USB booting options are also supported by the LoadMaster
installation ISO file.
2.2 Boot the Installed LoadMaster
The server is now ready to be rebooted with the LoadMaster software installed on the local disk.
Within the console, select the Ctrl-Alt-Del option from the Macros drop-down menu.
The server should now begin to boot from the local disk.
Occasionally, call trace code may appear while the LoadMaster is booting
up. This can be ignored.
The LoadMaster should obtain an IP address via DHCP, please note this value.
If the LoadMaster does not obtain an IP address via DHCP then the LoadMaster must be manually
configured using the console once the license key has been obtained.

Kemp LoadMaster Specifications

General

Layer 4/7 Load Balancing	Yes
High Availability	Yes
SSL Acceleration	Yes
Global Server Load Balancing (GSLB)	Yes
Model	Kemp LoadMaster
Category	Load Balancer
Virtual and Hardware Options	Yes
Product Type	Application Delivery Controller (ADC)
Form Factor	Hardware appliance, Virtual appliance
Application Firewall	Yes (via WAF functionality)
Vendor	Kemp Technologies
Protocols Supported	HTTP, HTTPS, TCP, UDP, SMTP, DNS, FTP, SIP
Load Balancing Methods	Round Robin
Security Features	SSL Offloading, WAF, DDoS Protection
Management Interface	Web-based GUI, CLI, API
Compliance	PCI DSS, HIPAA
Throughput	Varies by model (e.g., up to 100 Gbps)
