Configuring the LoadMaster via the Console
Copyright © 2002 - 2016 KEMP Technologies, Inc. All Rights Reserved. 14
3 Configuring the LoadMaster via the Console
If the LoadMaster does not automatically obtain an IP address using DHCP as described in
Section 2.1, or if you would prefer to configure the LoadMaster via the console, then the
following configuration steps must be completed before starting the LoadMaster:
1. Login in to the LoadMaster via the console using the following default credentials:
lb100 login: bal
Password: 1fourall
2. If required, change the LoadMaster password (for the bal user) when prompted to do so
within the console.
3. If required, press OK within the dialog box informing of the password change.
4. Press OK within Quick Setup Help dialog box.
Figure 3-1: Network Side Interface Address
5. Enter the IP address of the eth0 interface (the network facing interface of the LoadMaster)
in the input field within the Network Side Interface Address dialog box.
This value must be configured from within the console.
6. Press OK.
7. Enter the IP address of the eth1 interface in the input field within the Farm Side Interface
Address dialog box.
The eth1 interface is only configured if using a two-armed configuration.
This interface can be configured at a later date using the LoadMaster Web
User Interface (WUI) if preferred.
8. Press OK.
9. Enter the hostname (you can accept the default value of KEMP if desired) into the field of
the LoadMaster Hostname dialog box.
10. Click OK.
11. Enter the IP address(es) of the DNS Server(s) which will be used to resolve names locally on
the LoadMaster into the input field of the Name Server IP Addresses dialog box.
