EN
Creep Start 10…99 % Step: 1
OFF, CURVE (OFF=100%)
Factory setting is CURVE
CURVE means that the creep start value
comes from welding program.
StartPower -9…+9 Factory setting is 0 Adjusts arc ignition.
ADVANCED FUNCTIONS
WisePenet ON, OFF Penetration control selection
Penet%(123A) -30…+30 % Factory setting: 0 % WisePenetration percent setting. Set
penetration current.
WiseFusion ON, OFF WiseFusion selection
WiseFusion% 10…60 % or
CURVE
Factory setting is CURVE When WiseFusion is ON, it controls the
amount of short circuits in the arc. The
lower the value, the less short circuits
in the arc, and the higher the value, the
more short circuits in the arc.
MatchFunc * Minilog, MatchCh
OFF
Default is OFF Selects the type of function for
toggling between two sets of welding
parameters during welding:
Minilog=percentage of base current
MatchCh=alternative memory channel
MinilogLevel -99…+125 % Factory setting is 20 Sets the alternative current level to a
percentage of the base current
MatchMemChannel 0…9 Factory setting is 0 Sets the pre-dened memory channel,
where the alternative set of parameters
is stored
* MatchFunc is a function that allows you to use two pre-dened sets of welding parameters
during welding. You can toggle between these parameter sets by pressing the welding gun
trigger briey without having to stop welding.
SYSTEM CONFIG MENU
Water Cooling ON, OFF, AUTO Factory setting is AUTO Water cooler control.
ON: Water cooler is always ON
OFF: Water cooler is always OFF
AUTO: Water cooler starts when welding
starts and turns o after a delay when
welding stops.
Cable Length 10…100 m Step: 5
Factory setting is 10m
Welding cable loop length setting for
optimising arc control.
FineCalib 0V/100A…
10V/100A
Step: 0.1 V
Factory setting is
1.0V/100A
Fine Tuning Calibration Point.
Compensation for varying cable
resistance.
System Clock System Clock Settings
Device List Shows a list of connected devices.
17
© Kemppi Oy / 1312
