30 – Mastertig AC/DC 2000, 2500, 2500W, 3500W/0510
© COPYRIGHT KEMPPI OY
Mastertig AC/DC 3500W
Mains voltage
Rated power (U1=400V)
Connection cable
Fuse
Welding current range
Maximum load (T=40 °C)
Maximum load (T=20 °C)
Open circuit voltage
Frequency of AC
Efficiency
Power factor
Open circuit power
Storage temperature range
Operating temperature range
Temperature class / Degree of protection
External dimensions
Weight
Max liquid pressure of cooling unit
Rated power of cooling unit
– – – –
400 V ± 10 %
– – – –
350 A / 11,7 kVA
280 A / 8,2 kVA
350 A / 15,7 kVA
280 A / 11,2 kVA
4 x 2,5 mm
2
S - 5 m
20 A delayed
3 A / 10 V...350 A / 24 V
10 A / 10 V...350 A / 24 V
10 A / 20 V...350 A / 34 V
350 A / 24 V
280 A / 21,2 V
350 A / 34 V
280 A / 31,2 V
310 A / 22,4 V
350 A / 34 V
300 A / 32 V
70 V DC
60 Hz / 50 ... 200 Hz
80 % (350 A / 34 V)
0,9 (350 A / 34 V)
18 W
-40 ... +60 °C
-20 ... +40 °C
B (130 °C), H (180 °C) / IP 23C
690 mm
260 mm
870 mm
74 kg
350 kPa
1300 W
3~ 50 / 60 Hz
TIG 60 % ED
TIG 100 % ED
MMA 60 % ED
MMA 100 % ED
400 V
TIG DC
AC
MMA
TIG AC 60 % ED
100 % ED
MMA DC 60 % ED
100 % ED
TIG AC 100 % ED
MMA DC 80 % ED
100 % ED
(AC ja DC)
fixed / adjustable*)
length
width
heigh
*) Adjustable with MINILOG- and PULSE panels.
**) Fuse can reduce maximum load.
The products meet conformity requirements for CE marking.
