Kemppi MASTERTIG AC/DC 2000 - 2. INSTALLATION; 2.1. CABLING THE MACHINE

Mastertig AC/DC 2000, 2500, 2500W, 3500W/0510 – 5
© COPYRIGHT KEMPPI OY
Mastertig AC/DC 2000
Mastertig AC/DC 2500
2. INSTALLATION
2.1. CABLING THE MACHINE
Shielding gas hose
Gas-cooled TIG
torch
Cable for MMA
welding
Return current
cable
Remote control unit
Mains cable
Shielding gas hose
Cable for MMA
welding
Remote control
unit
Gas-cooled TIG
torch
Return current
cable
Mains cable
