Kemppi MasterTig MLS 3003 ACDC Service Manual

2
Technical data
The device may be repaired only by a person legally authorized
perform electric work!
Measured values may differ by the type and model of multimeter used.
Maximum power can be achieved with 20 kVA generator for the power source.
Mains Voltage 3 ~ 230 V - 10% … 460 V +10%, 50/60 Hz
Mains cable H07RN-F 4G2.5, length 5 m
Fuse 20/ 16A delayed fuse
Rated power 40% 100%
TIG 300A TIG 190A
MMA 250A MMA 190A
Minimum Current TIG 3A ( AC 5A ) / MMA 10A
Open circuit Voltage 58 V
Power Factor at nominal values 0,95
Efficiency at nominal values 80-84 % (250A / 30V)
77-81 % (300A / 22V)
Open circuit power TIG < 13W
MMA 190W
Electrode sizes to be welded 1,5 - 5,0 mm
Size ( l x w x h ) 500 x 180 x 390 mm
Weight 25 kg
