Kemppi MasterTig MLS 3003 ACDC Service Manual

3
User interface
1. 2.
3.
4.
5.
6.
1. Gas connector for TIG torch
2. Welding current connection (negative)
3. Operation panel
4. Remote controller connection
5. TIG -torch control connection
6. Welding current connection (positive)
7. Main switch
8. Gas connector
7
8.
Error code Description
Err 3 Overvoltage
Err 4 Over heating
Err 6 Internal fault, secondary voltage over the limit.
Err 8 Maximum overheat time, machine doesn’t cool down fast enough. Only machine
shutdown and restart removes error.
Err 61 Water connection, water cooled gun connected without cooler.
COO Ler Cooler error:
- Cooling liquid over- / under pressure state
- Overheated alarm
BuS Err Communication between panel and power source isn’t possible
Err rSt System error, machine makes reset itself.
