Kenmore 148.1615421 - Page 17

17
Loosen the two screws in the right and left angle brackets 3 to 4 turns.
Insert the screws through the 2 holes at the base of each side panel and slide the bracket down until
it stops. Attach each bracket to the bottom panel with one 3/16-24 x 3/8 in. screw. Retighten the 4
loosened screws.
Attach the beam to side panels with four 3/16-24 x 3/8 in. screws as shown.
Right Panel
Left Panel
Beam
3/16-24 x 3/8 in. Screw
Qty. 2
3/16-24 x 3/8 in. Screw
Qty. 4
Rear Panel
