INSTALLING MACHINE HEAD
Loosen the two hinge screws under holes in the rear
edge of the machine bed (1).Raise hinge pins in the
cutout (2).Slip machine head onto the pins and
tighten hinge screws securely (3).
Lower machine head to front flap.
SEWING LIGHT
The sewing light is place inside the face cover plate
as shown. It may be turned on or off by pushing
light switch.
In order to operate the machine, the
switch must be on.
To remove bulb, turn light switch off, open the face
cover plate by swinging it open, push bulb in
slightly, turn bulb clockwise and remove from
socket. To replace, push in new bulb in and turn
counter clockwise. See illustration 4.
CONNECTING MACHINE
Push the plug onto three-prong connector under the
bed plate. Plug machine cord into any 110-120V wall
outlet. See illustration 5.
4
