Kenmore 35932 - Page 45

- 5 - 11/04
35932
CAUTION: Use the Kenmore part number on all orders, n
ot
the illustration number.
CONTROL BOX ASSEMBLY
# = Functional Parts
* = Non-illustrated Parts
1-B
2-B
3-B
4-B
5-B
6-B #
7-B
8-B
9-B #
10 - B
11 - B
12 - B
13- B
PART NUMBER
MBN35986901
MGC35987201
MDD42355804
EBR39264104
EBR30852301
2H01451M
6631A30012E
6411A20056T
6323A20004S
6631A30027C
6631A10011K
6631A30003A
6711A20056T
DESCRIPTION
CONTROL BOX
PANEL, CONTROL
ESCUTCHEON
PWB ASSEMBLY, MAIN
PWB ASSEMBLY, DISPLAY
CAPACITOR
CONNECTOR ASSEMBLY
POWER CORD ASSEMBLY
THERMISTOR ASSEMBLY
CONNECTOR ASSEMBLY
CONNECTOR ASSEMBLY
CONNECTOR ASSEMBLY
REMOTE CONTROLLER ASSEMBLY
ILLUSTRATION
NUMBER
14- B MBN
35987101 COVER
15- B 3550A20257B
PCB,COVER
