Kenmore 35932 - Page 49

- 9 - 11/04
35932
CAUTION: Use the Kenmore part number on all orders, n
ot
the illustration number.
COMPRESSOR PARTS
# = Functional Parts
* = Non-illustrated Parts
1-D
2-D
3-D
4-D #
5-D
6-D #
7-D
8-D
9-D
10 - D
11 - D
12 - D
13 - D
PART NUMBER
4H00947A
4H01058A
3550U-L006A
6750U-L005A
4986U-L001G
2520UCBA016
1NHA0801206
4810AR4155A
4H00982C
5211A29026A
5211A20560J
5211A24022A
5211A21421G
DESCRIPTION
NUT, DRAWING
WASHER, DRAWING
COVER
OVER LOAD PROTECTOR
GASKET
COMPRESSOR
HEXAGON NUTS
BRACKET, COMP
ISOLATOR, COMP
TUBE ASSEMBLY, EVAPORATOR IN
TUBE ASSEMBLY, CONDENSER OUT
TUBE ASSEMBLY, SUCTION
TUBE ASSEMBLY, DISCHARGE
ILLUSTRATION
NUMBER
