SERVICE TECH. INFORMATION
SECTION 5
22
5A. ELECTRICAL CONNECTIONS
IMPORTANT:
Keepthismanualwithyourwatersoftener.Ifrepairsareneeded,theservice technicianmusthavethe
information on the following pages. For telephone assistance, call toll free, 1-800-426-9345.
PRESENT TIME
RECHARGE TIME
RECHARGE DAY
SET / CLEAR
ON / OFF
VACATION
HOLD RECHARGE NOW
Solid State Water Softener
FACEPLATE TIMER
