Why is my Kenmore 795.71022.010 Poor Defrosting?
Poor defrosting in your Kenmore Refrigerator can stem from several causes: a disconnected temperature fuse, a faulty heater, a jammed drain, or a poor relay for the heater. Unfortunately, further details on how to resolve these specific issues are not provided.
What to do if my Kenmore 795.71022.010 shows a Communication Error?
If your Kenmore Refrigerator shows a Communication Error, it's likely due to a poor connection in communication or a faulty TR (Transmitter and Receiver). Check the communication connection and the TR of the transmitter and receiver.
What causes Abnormality of Brushless DC FAN Motor for Freezer in Kenmore 795.71022.010?
If there's an Abnormality of Brushless DC FAN Motor for Freezer in your Kenmore Refrigerator, it typically occurs when the F/B signal doesn’t exceed 65 seconds during motor operation. Possible solutions include checking for a poor BLDC Motor connection, DRIVE IC, and TR.
What causes Abnormality of Brushless DC FAN Motor for Ice Making in Kenmore Refrigerator?
If there's an Abnormality of Brushless DC FAN Motor for Ice Making in your Kenmore Refrigerator, it typically occurs when the F/B signal doesn’t exceed 65 seconds during motor operation. Possible solutions include checking for a poor BLDC Motor connection, DRIVE IC, and TR.
What causes Abnormality of Brushless DC FAN Motor for Mechanic Room in Kenmore 795.71022.010 Refrigerator?
If there's an Abnormality of Brushless DC FAN Motor for Mechanic Room in your Kenmore Refrigerator, it typically occurs when the F/B signal doesn’t exceed 65 seconds during motor operation. Possible solutions include checking for a poor BLDC Motor connection, DRIVE IC, and TR.
Details technical specifications for the refrigerator.
Identifies and labels various parts of the refrigerator.
Provides step-by-step instructions for dismantling refrigerator components.
Covers procedures for adjusting specific refrigerator components.
Displays the electrical schematic of the refrigerator's circuits.
Offers guidance for diagnosing and resolving common refrigerator issues.
Shows visual representations of the main Printed Circuit Board (PCB).
Addresses troubleshooting steps based on specific error codes displayed.
Provides troubleshooting for issues without error codes on the display.
Contains supplementary information and technical references for service.
Details methods for testing individual refrigerator components.
Further troubleshooting guidance for refrigerator system issues.
Explains the icemaker's operation and repair procedures.
Describes the functions and circuitry of the microcomputer control.
Emphasizes safety by disconnecting power before service.
Provides general warnings and disclaimers for service personnel.
Lists the electrical ratings and consumption of the refrigerator.
Details performance metrics under no-load conditions.
Outlines the specifications of the refrigeration cycle components.
Specifies clearance requirements for refrigerator installation.
Lists common parts available for replacement.
Illustrates the air circulation paths within the refrigerator.
Provides detailed physical dimensions of the refrigerator.
Identifies major parts of the refrigerator with labels.
Step-by-step guide for door removal and installation.
Critical safety warning regarding electrical hazards during service.
Procedures for door gasket removal and replacement.
Procedures for aligning refrigerator doors properly.
Instructions for disassembling the evaporator fan and motor.
Steps to replace the ice fan scroll assembly.
Details on the defrost control assembly and its components.
Instructions for replacing the refrigerator compartment lamp.
Instructions for removing and servicing the multi-duct assembly.
Guide for replacing the freezer compartment light bulb.
Procedure for removing and replacing the main Printed Circuit Board (PCB).
Instructions for accessing and removing the dispenser unit.
Steps to replace the display Printed Circuit Board (PCB).
Procedure for replacing the dispenser funnel.
Instructions for replacing the sub PCB for the dispenser.
Steps for replacing the duct door assembly.
Instructions for replacing the ice corner door.
Procedure for removing and replacing the icemaker assembly.
Steps to remove the auger motor cover.
Guide on how to take out the door ice bin.
Guide on how to put in the door ice bin.
Detailed steps for removing and reinstalling the pullout drawer.
Reinstallation steps for the pullout drawer.
Procedure for disassembling the water valve.
Instructions for disassembling the fan and fan motor.
Instructions for removing and installing the pull-out drawer.
Explains the role and usage notes for the compressor.
Describes the primary function of the compressor.
Important precautions and guidelines for compressor usage.
Steps to remove the cover for the PTC component.
Overview of the E-Linear compressor technology.
Visual representation of the compressor control system.
Describes the compressor's operating cycle and patterns.
Details the various protection mechanisms for the compressor.
Guide for diagnosing compressor issues through resistance checks.
Procedure for checking compressor voltage.
Diagnosing compressor issues using LED blinking patterns on the sub PCB.
Electrical schematic showing the refrigerator's wiring and components.
Table listing error codes, their causes, and troubleshooting actions.
Visual identification of the main Printed Circuit Board (PCB) and its connectors.
Visual identification of the display and sub PCBs with connectors.
Troubleshooting steps for the freezer sensor error code.
Troubleshooting steps for the refrigerator sensor error code.
Troubleshooting steps for the icing sensor error code.
Troubleshooting steps for the defrost sensor error code.
Troubleshooting steps for the defrost heater error code.
Troubleshooting steps for the freezer fan error code.
Troubleshooting steps for the icing fan error code.
Troubleshooting steps for the condenser fan error code.
Troubleshooting steps for communication errors between components.
Troubleshooting for the ice maker cube mode not functioning.
Troubleshooting for the ice maker crush mode not functioning.
Troubleshooting for the water dispenser mode not functioning.
Troubleshooting for the freezer compartment light not working.
Troubleshooting for the refrigerator compartment light not working.
Troubleshooting steps for insufficient cooling in the fresh food section.
Method for checking the damper and its PCB.
Instructions for checking the fan motor's condition.
How to check the voltage supply to the freezer fan motor.
Troubleshooting steps for insufficient cooling in the freezer compartment.
Troubleshooting steps for excessive cooling in the fresh food section.
How to enter test mode and remove Terminal Position Assurance.
Chart showing resistance and voltage values for freezer/icing sensors at various temperatures.
Chart showing resistance and voltage for refrigerator/defrost sensors.
Procedure for diagnosing fan errors based on MICOM feedback.
Steps for troubleshooting compressor issues, including LED blinking checks.
Guide on how to respond to different LED blinking patterns for compressor errors.
Information on testing the defrost controller assembly components (Fuse-M and Sensor).
Procedure for testing the sheath heater for defrost function.
Instructions for testing the door heater assembly.
How to test the door switches for proper operation.
Procedure for testing the dispenser DC motor.
Instructions for testing the ice auger motor assembly.
Testing procedures and resistance values for the damper.
How to test the light bulb socket for continuity.
Procedure for testing the flow sensor.
Details on compressor model, refrigerant, and safety approval.
Describes compressor stroke and power patterns for different inverter types.
Table of inverter error codes, requirements, and LED flashes.
Procedure for checking IPM voltage output during operation.
Checks for compressor insulation and winding resistance.
Comprehensive chart for diagnosing common refrigerator complaints.
Troubleshooting steps for a "No Cooling" complaint.
Troubleshooting steps for poor cooling performance.
Diagnosing why food in the refrigerator is freezing.
Troubleshooting condensation and ice buildup issues.
Diagnosing condensation on the exterior of the refrigerator.
Troubleshooting sources of abnormal noise.
Steps to resolve issues with the door not closing properly.
Addressing unpleasant odors from ice and food.
Diagnosing other potential issues like freezer frost or refrigeration system faults.
Chart categorizing refrigeration problems by cause and symptoms.
Diagnostic flowchart for "Not Cooling" complaints related to the sealed system.
Explains the operational flow and stages of the icemaker.
Details the various modes and functions of the ice maker.
Describes the icemaking process and completion criteria.
Explains the harvest mode for dropping ice and checks for ice bin fullness.
Details the fill/park position and water supply adjustment.
Procedure for performing forced operations for testing and service.
Automatic diagnosis feature and how defect codes are displayed.
Lists error codes displayed on the ice maker control panel.
General functions of the refrigerator's control system.
Initial settings and temperature adjustments.
Method to switch temperature display units.
How to activate and deactivate the control panel lock feature.
Information on the water filter replacement indicator.
Description of the Ultra Ice function for rapid freezing.
How to select water or ice dispensing options.
Explanation of dispenser light modes (Normal, Auto, On).
How the freezer fan motor speed is controlled.
Control of the cooling fan motor based on temperature and operation.
Control of the ice compartment fan based on sensor input.
Detailed explanation of the Ultra Ice function's operation and duration.
How the door open alarm buzzer operates.
How to enter and exit a special display mode.
Explains the defrosting cycle timing and conditions.
Automatic diagnosis feature and how defect codes are displayed.
List of applicable model numbers for the manual.
Diagram and list of valve and water tube components.
Exploded view diagram of the refrigerator's case parts.
Detailed list of case parts with part numbers and descriptions.
Continuation of the detailed case parts list.
Exploded view diagram of freezer compartment parts.
Exploded view diagram of refrigerator compartment parts.
Exploded view diagram of refrigerator door parts.
Detailed list of door parts with part numbers and descriptions.
Exploded view diagram of dispenser assembly parts.
Exploded view diagram of ice maker and ice bank components.
Details technical specifications for the refrigerator.
Identifies and labels various parts of the refrigerator.
Provides step-by-step instructions for dismantling refrigerator components.
Covers procedures for adjusting specific refrigerator components.
Displays the electrical schematic of the refrigerator's circuits.
Offers guidance for diagnosing and resolving common refrigerator issues.
Shows visual representations of the main Printed Circuit Board (PCB).
Addresses troubleshooting steps based on specific error codes displayed.
Provides troubleshooting for issues without error codes on the display.
Contains supplementary information and technical references for service.
Details methods for testing individual refrigerator components.
Further troubleshooting guidance for refrigerator system issues.
Explains the icemaker's operation and repair procedures.
Describes the functions and circuitry of the microcomputer control.
Emphasizes safety by disconnecting power before service.
Provides general warnings and disclaimers for service personnel.
Lists the electrical ratings and consumption of the refrigerator.
Details performance metrics under no-load conditions.
Outlines the specifications of the refrigeration cycle components.
Specifies clearance requirements for refrigerator installation.
Lists common parts available for replacement.
Illustrates the air circulation paths within the refrigerator.
Provides detailed physical dimensions of the refrigerator.
Identifies major parts of the refrigerator with labels.
Step-by-step guide for door removal and installation.
Critical safety warning regarding electrical hazards during service.
Procedures for door gasket removal and replacement.
Procedures for aligning refrigerator doors properly.
Instructions for disassembling the evaporator fan and motor.
Steps to replace the ice fan scroll assembly.
Details on the defrost control assembly and its components.
Instructions for replacing the refrigerator compartment lamp.
Instructions for removing and servicing the multi-duct assembly.
Guide for replacing the freezer compartment light bulb.
Procedure for removing and replacing the main Printed Circuit Board (PCB).
Instructions for accessing and removing the dispenser unit.
Steps to replace the display Printed Circuit Board (PCB).
Procedure for replacing the dispenser funnel.
Instructions for replacing the sub PCB for the dispenser.
Steps for replacing the duct door assembly.
Instructions for replacing the ice corner door.
Procedure for removing and replacing the icemaker assembly.
Steps to remove the auger motor cover.
Guide on how to take out the door ice bin.
Guide on how to put in the door ice bin.
Detailed steps for removing and reinstalling the pullout drawer.
Reinstallation steps for the pullout drawer.
Procedure for disassembling the water valve.
Instructions for disassembling the fan and fan motor.
Instructions for removing and installing the pull-out drawer.
Explains the role and usage notes for the compressor.
Describes the primary function of the compressor.
Important precautions and guidelines for compressor usage.
Steps to remove the cover for the PTC component.
Overview of the E-Linear compressor technology.
Visual representation of the compressor control system.
Describes the compressor's operating cycle and patterns.
Details the various protection mechanisms for the compressor.
Guide for diagnosing compressor issues through resistance checks.
Procedure for checking compressor voltage.
Diagnosing compressor issues using LED blinking patterns on the sub PCB.
Electrical schematic showing the refrigerator's wiring and components.
Table listing error codes, their causes, and troubleshooting actions.
Visual identification of the main Printed Circuit Board (PCB) and its connectors.
Visual identification of the display and sub PCBs with connectors.
Troubleshooting steps for the freezer sensor error code.
Troubleshooting steps for the refrigerator sensor error code.
Troubleshooting steps for the icing sensor error code.
Troubleshooting steps for the defrost sensor error code.
Troubleshooting steps for the defrost heater error code.
Troubleshooting steps for the freezer fan error code.
Troubleshooting steps for the icing fan error code.
Troubleshooting steps for the condenser fan error code.
Troubleshooting steps for communication errors between components.
Troubleshooting for the ice maker cube mode not functioning.
Troubleshooting for the ice maker crush mode not functioning.
Troubleshooting for the water dispenser mode not functioning.
Troubleshooting for the freezer compartment light not working.
Troubleshooting for the refrigerator compartment light not working.
Troubleshooting steps for insufficient cooling in the fresh food section.
Method for checking the damper and its PCB.
Instructions for checking the fan motor's condition.
How to check the voltage supply to the freezer fan motor.
Troubleshooting steps for insufficient cooling in the freezer compartment.
Troubleshooting steps for excessive cooling in the fresh food section.
How to enter test mode and remove Terminal Position Assurance.
Chart showing resistance and voltage values for freezer/icing sensors at various temperatures.
Chart showing resistance and voltage for refrigerator/defrost sensors.
Procedure for diagnosing fan errors based on MICOM feedback.
Steps for troubleshooting compressor issues, including LED blinking checks.
Guide on how to respond to different LED blinking patterns for compressor errors.
Information on testing the defrost controller assembly components (Fuse-M and Sensor).
Procedure for testing the sheath heater for defrost function.
Instructions for testing the door heater assembly.
How to test the door switches for proper operation.
Procedure for testing the dispenser DC motor.
Instructions for testing the ice auger motor assembly.
Testing procedures and resistance values for the damper.
How to test the light bulb socket for continuity.
Procedure for testing the flow sensor.
Details on compressor model, refrigerant, and safety approval.
Describes compressor stroke and power patterns for different inverter types.
Table of inverter error codes, requirements, and LED flashes.
Procedure for checking IPM voltage output during operation.
Checks for compressor insulation and winding resistance.
Comprehensive chart for diagnosing common refrigerator complaints.
Troubleshooting steps for a "No Cooling" complaint.
Troubleshooting steps for poor cooling performance.
Diagnosing why food in the refrigerator is freezing.
Troubleshooting condensation and ice buildup issues.
Diagnosing condensation on the exterior of the refrigerator.
Troubleshooting sources of abnormal noise.
Steps to resolve issues with the door not closing properly.
Addressing unpleasant odors from ice and food.
Diagnosing other potential issues like freezer frost or refrigeration system faults.
Chart categorizing refrigeration problems by cause and symptoms.
Diagnostic flowchart for "Not Cooling" complaints related to the sealed system.
Explains the operational flow and stages of the icemaker.
Details the various modes and functions of the ice maker.
Describes the icemaking process and completion criteria.
Explains the harvest mode for dropping ice and checks for ice bin fullness.
Details the fill/park position and water supply adjustment.
Procedure for performing forced operations for testing and service.
Automatic diagnosis feature and how defect codes are displayed.
Lists error codes displayed on the ice maker control panel.
General functions of the refrigerator's control system.
Initial settings and temperature adjustments.
Method to switch temperature display units.
How to activate and deactivate the control panel lock feature.
Information on the water filter replacement indicator.
Description of the Ultra Ice function for rapid freezing.
How to select water or ice dispensing options.
Explanation of dispenser light modes (Normal, Auto, On).
How the freezer fan motor speed is controlled.
Control of the cooling fan motor based on temperature and operation.
Control of the ice compartment fan based on sensor input.
Detailed explanation of the Ultra Ice function's operation and duration.
How the door open alarm buzzer operates.
How to enter and exit a special display mode.
Explains the defrosting cycle timing and conditions.
Automatic diagnosis feature and how defect codes are displayed.
List of applicable model numbers for the manual.
Diagram and list of valve and water tube components.
Exploded view diagram of the refrigerator's case parts.
Detailed list of case parts with part numbers and descriptions.
Continuation of the detailed case parts list.
Exploded view diagram of freezer compartment parts.
Exploded view diagram of refrigerator compartment parts.
Exploded view diagram of refrigerator door parts.
Detailed list of door parts with part numbers and descriptions.
Exploded view diagram of dispenser assembly parts.
Exploded view diagram of ice maker and ice bank components.
General| Brand | Kenmore |
|---|---|
| Model Number | 795.71022.010 |
| Category | Refrigerator |
| Type | French Door |
| Ice Maker | Yes |
| Water Dispenser | Yes |
| Color | Stainless Steel |
| Width | 35.75 inches |
| Energy Star Certified | Yes |
To Next Page
