Kenmore D02 M90230 - Page 17

466724112 • 17
3
Hook the short tank exclusion wire(silver) onto front right leg. Flex tank exclusion wire to fit other end to the hole on
of rear rail. bottom edge
Rear Rail
Short Tank Exclusion (silver)
Front Right Leg
Hook the long tank exclusion wire(black) onto front left leg. Flex tank exclusion wire to fit other end to rear right leg.
4
Long Tank Exclusion (black)
Rear Right Leg
