18 • 466724112
5
6
This step requires two people to lift and position grill head onto cart.
Carefully lower the grill head onto the cart. Make sure the regulator hose is hanging inside the cart.
Slide grill head from rear to front of cart until the pre-installed screws slide into the opening of the metal tabs.
Tighten the .pre-installed screws
A
Grill Head
Slide keyhole slots in the right side shelf over the five pre-installed screws on the right side of the
firebox (A). Tighten the pre-installed screws (B).
B
To Next Page
