This feature allows the cooktop to be locked only when the
cooktop is switched to OFF.
To turn ON the Controls Lock feature, touch and hold the
LOCK key pad for 3 seconds. A beep will sound and the
Lock LED will glow (Fig. 14). Once locked, no other displays
will glow and no Cooking Zones will activate (Except the hot
surface message “HE” if the zone is hot).
To turn the Controls Lock OFF, touch and hold the LOCK key
pad for 3 seconds. A beep will sound, the Lock LED will turn
OFF (Fig. 13) and the cooktop may be used normally.
Cooktop Control Pads
Cooktop Power Pad
The Cooktop POWER key pad activates the entire Cooktop.
To power the cooktop, touch and hold the POWER key pad
for 2 seconds. A beep will sound and the Power LED will glow
(Fig. 12). The cooktop will be in a ready mode for 10 seconds.
If no other key pads are touched the Cooktop Main POWER
will turn OFF automatically.
To turn the Main Power OFF touch and hold the Main POWER
key pad for 1 second. A beep will sound and the Power LED
will turn OFF (Fig. 11).
Using the Slider Zone Control
The Slider zone control is a new and innovative way to set
your cooking zone power. Heat is controlled by just the
touch of a nger, resulting in a clean look uncluttered by
knobs or dials. These controls are intuitive, precise and very
stylish. Three methods of setting these controls are available
for a better ease of use.
Once the cooktop is active, touch the Cooking Zone On/O
pad (Fig. 16) to activate the slider zone control.
When the cooking zone is on, press the Warm & Hold pad
(Fig. 17 to keep food at serving temperature.
Using the Touch Control
Be sure that your nger is placed in the center of the touch
pad. If the nger is not placed on the center of a pad, the
cooktop may not respond to the selection made.
Lightly contact the pad with the at part of your entire
ngertip. Do not just use the narrow end of your ngertip.
Minute Timer
The Minute Timer feature may be useful in the kitchen if
a recipe calls for keeping track of time. This feature will
keep track of time from 1 to 99 minutes. The Alpha-Numeric
display located to the left of the Timer UP/DOWN arrow
key pads will begin to count down minutes once set.
To Set the Minute Timer:
1. Set the cooktop timer to the desired time by touching
the listed under the word “TIMER”. Touching and
releasing the or the key pads will increase or
decrease the Minute Timer setting by 1 minute with each
key press (up to 99 minutes). You may also hold the or
key to slew the time to your designated time.
2. Once the Timer Alpha-Numeric displays the desired
amount of time, release the or Arrow key pads.
The timer will display the time remaining in minutes within
the countdown process. During the last 60 seconds, the
timer will countdown in seconds.
Note: After the timer is set, it is normal for the displayed
value to automatically go down by one minute. This is
due to the fact that the display only shows the minutes
remaining and does not show the countdown process in
the back ground. For example when setting the timer for
3 minutes, the timer will start counting down at 02 min 59
seconds, but the timer display will only show 02 minutes,
not the remaining seconds.
Once the Minute Timer reaches 00 a long beep will sound
every 5 seconds until
and key pads are touched at
the same time and the timer Alpha-Numeric display will
ash “00” indicating that the time is up.
To Cancel the Minute Timer:
At any time to cancel the
minute timer, press the Timer
Set/O pad.
