- 8 -
1. Insert the charging adapter into the
charging port located on the left of the
hand vacuum.
1. Fit the vacuum body into the motorized
nozzle and lock into place.
2. Insert the handle into the top of the main
body, as illustrated, and lock into place.
Before assembling the vacuum cleaner, check the PACKING LIST (Page 2). Use this list to
verify that you have received all the components of your new Kenmore Cordless 2-in-1
Stick Vacuum.
ASSEMBLY INSTRUCTIONS
3. Insert the hand
vacuum into the main
body as shown and
lock into place.
Ensure that the dust
cup is secured in
place.
WARNING
Before charging make sure the unit is
turned OFF.
Click!
Click!
1
2
Charging
Port
CHARGING
To Next Page
