04-12
11
Klenzor
16, 18 MPH
HANDLE SYSTEM 18
06-10
FORM NO. 56042453
Item Ref. No. Qty Description
1 56265097 1 Switch, Rocker (vacuum)
2 56265107 1 Switch, Rocker (solution)
3 56262518 1 Hook, Cord
4 56009095 2 Nut, Conduit Lock 1/2-14
5 56111503 2 Bearing, Flange
6 56056519 2 Compression Spring
7 56265198 1 Bag, Utility
8 56001841 2 Scr, Soc Set Loc 1/4-20 x .25
9 56009003 2 Wsh, Flt .516 x .938 x .075
10 56486112 1 Clamp, P
11 56002066 2 Scr, Pan Phil 1/4-20 x .62
12 56002395 6 Scr, Flt Phil 5/16-18 x .75
13 56009341 2 Scr, Button Soc 1/2-13 x 1.50
14 56002840 1 Nut, Hex Nyl Loc-Thin 1/4-20
15 56002843 2 Nut, Hex Nyl Loc-Thin 1/2-13
16 56003092 2 Scr, Pan Phil Plastite 4-20 x .62
17 56002098 2 Wsh, FLT SAE 1/4
18 56003284 2 Nut, Hex Nyl Loc 1/4-28
19 56009029 2 Scr, Pan Phil Thd Form 10-24 x .50
20 56009066 2 Scr, Pan Phil 8-32 x .31
21 56009131 4 Scr, Soc Set Loc 5/16-18 x .31
22 56009139 4 Scr, Pan Phil Loc 10-24 x .38
23 56009191 9 Scr, Pan Phil Plastite 10-14 x .50
24 56265241 2 Handle Adjustment Pivot NOTE 1
25 56265028 1 Cover, Handle, Front
26 56265162 1 Cord, Power 14/3, SJT
27 56265053 1 Button, Spray
28 56265054 1 Bail, Handle Release
29 56265055 1 Panel, Control
30 56265056 1 Circuit Breaker W/Boot (5 amps)
31 56265062 1 Cover, Flip Handle, Back
32 56265074 2 Gear, Handle
33 56265083 2 Handle Socket
34 56265084 2 Lock, Handle
35 56002832 3 Nut, Hex Nyl Loc-Thin 10-24
36 56265098 1 Switch, SPDT Snapaction
37 56002231 3 Scr, Pan Phil 10-24 x 1.50
38 56265128 2 Bellows, Handle
39 56265147 2 Wire Rope Assy
40 56265157 1 Tube, Handle
41 56265242 2 Pin NOTE 2
42 56265192 1 Main Cable Assy
43 56265197 1 Tube, Handle
NOTE 1: Pivot Weldment 56265023 is obsolete and has been replaced by Handle Adjustment Pivot 56265241 in production. Order Kit 56265191 when replacing
56265023.
NOTE 2: Pin 56265164 is obsolete and has been replaced by Pin 56265242 in production. Order Kit 56265191 when replacing 56265164
HANDLE SYSTEM 18
