KENT Klenzor 16 MPH Parts List

04-12
19
Klenzor
™
16, 18 MPH
WIRING DIAGRAM
FORM NO. 56042453
Item Ref. No. Qty Description
D1 56265103 1 Rectifi er, 35 Amp
F1 56265056 1 Circuit Breaker, 5 Amp
L1 56265037 1 Valve, Solenoid 115V
M1 56265096 1 Motor Vacuum, 120V
* 56264453 1 Carbon Brushes for 56265096 (one pair)
M2 56265075 1 Motor, Brush 115 VDC, 1/3 HP
M3 56265051 1 Motor, Pump 115V
S1 56265097 1 Switch, Mode Selection
S2 56265053 1 Switch, Intermittent Spray
S3 56265107 1 Switch, Constant Spray (18 only)
* 56265187 1 Wire Assembly (16, 18)
* 56265102 1 Wire Assembly (16, 18)
* 56265087 1 Wire Assembly (16, 18)
* 56265108 2 Wire Assembly (18)
* = Not Shown
WIRING DIAGRAM
06-10

KENT Klenzor 16 MPH Specifications

General

Brand	KENT
Model	Klenzor 16 MPH
Category	Floor Machine
Language	English
