KENT Klenzor 16 MPH Parts List

04-12
3
Klenzor
™
16, 18 MPH
05-3
FORM NO. 56042453
BASE SYSTEM
Item Ref. No. Qty Description
1 56265067 1 Shoe Assembly, 16 (Klenzor 16) (items 2-5)
56265080 1 Shoe Assembly, 18 (Klenzor 18) (items 2-5)
2 56002865 6 Nut, Hex Nyl Loc-Thin 8-32
3 56002101 6 Scr, Soc Hd 8-32 x 0.50
4 56265068 1 Shoe Front, 16
56265081 1 Shoe Front, 18
5 56265069 1 Shoe Back, 16, Assy
56265082 1 Shoe Rear, 18, Assy
6 56002959 1 Pin, Cotter Hair
7 56009095 1 Nut, Conduit Lock 1/2-14
8 56398606 1 Spring, Ext .50 x 6.25
9 56002166 1 Pin, Cotter 3/32 x 3/4
10 56171095 2 Bearing, Flange
11 Intentionally Omitted
12 56265172 1 Panel, Exhaust
13 56228142 2 Spring, Compression
14 56265116 1 Linkage Weldment, 16 (16)
56265144 1 Linkage Weldment, 18 (18)
15 56002844 1 Nut, Hex Nyl Loc-Thin 5/8-11
16 56002865 1 Nut, Hex Nyl Loc-Thin 8-32
17 56260071 1 Terminal Block
18 56265103 1 Rectifi er, 35 Amp
19 56365548 1 Lock Pin Assy
20 56265111 1 Adjustment Rod Weldment
21 56002022 1 Wsh, Flt SAE 5/8
22 56265073 2 Pin, Pivot
23 56002146 1 Scr, Pan Phil 8-32 x .62
24 56009060 2 Wsh, Flt SS .260 x 1.000 x .074
25 56265071 1 Gasket, Exhaust
26 56249505 2 Wheel
27 56003091 1 Scr, Pan Phil Plastite 10-14 x .75
28 56003120 2 Pin, Cotter Hair .0915 x .375
29 56003133 1 Pin, Spr .12 x .56
30 56003207 1 Clevis Pin .50 x 2.75
31 56002832 1 Nut, Hex Nyl Loc-Thin 10-24
32 56003691 2 Scr Hex Loc SS 1/4-20 x 4.50
33 56009097 2 Nut, Push Cap 1/2
34 56265057 1 Axle
35 56009191 5 Scr, Pan Phil Plastite 10-14 x .50
36 56200573 1 Gasket, Ring 1.75 x 2.75 x .19
37 56265020 1 Base, Extractor, 16 (16)
56265120 1 Base, Extractor, 18 (18)
38 56265031 1 Clip, Rod
39 56265036 1 Knob, Brush Adjustment
40 56002674 1 Scr, Pan Phil 10-24 x 1.00
41 56265119 1 Latch, Adjustment
42 56002098 2 Wsh, Flt SAE 1/4
43 56003193 1 Clevis Pin .25 x 1.625
