Optional Accessory Connection
TV ANTENNA INPUT
TO MONITOR UNIT
To KCA-BT200 (Optional Accessory)
KCA-iP300V
(Optional Accessory)
iPod
(commercially available)
TV Tuner
(Optional Accessory)
Connection cable
(Included in the TV tuner)
Audio Output (Black)
Video Input
Video Output (Yellow)
Audio Input
USB terminal
USB terminal
Accessory 5
