Setting up the system
Connecting video components
Video inputs and outputs
(Yellow RCA pin cords)
Audio inputs
and outputs
OUT OUT
Monitor TV
Video inputs
(Yellow RCA pin cords)
VIDEO
IN
A video component with digital audio outputs should be connected to the VIDEO 2 jacks.
Video OUT
Audio OUT
Video OUT Audio OUT
DVD player or LD player
DVD player or LD player
