Page #36 background imageLoading...
Page #36 background image
PARTS LIST
Indicates safety critical components.
Ref. No.
L:
Scandinavia
K:
USA
P:
Canada
R:
Mexico
C:
China
I:
Malaysia
Y:
PX(Far East,Hawaii)
T:
England
E:
Europe
G:
Germany
V:
China(Shaghai)
Y:
AAFES(Europe)
X:
Australia
Q:
Russia
H:
Korea
M:
Other Areas
✽
New parts
Parts without
Parts No.
are not supplied.
Les articles non mentionnes dans le
Parts No.
ne sont pas fournis.
Teile ohne
Parts No.
werden nicht geliefert.
KRF-V6200D/V7200D
36
Add-
ress
Parts No.
New
Parts
Description
Desti-
nation
Re-
marks
Ref. No.
Add-
ress
Parts No.
New
Parts
Description
Desti-
nation
Re-
marks
✽
New parts
Parts without
Parts No.
are not supplied.
Les articles non mentionnes dans le
Parts No.
ne sont pas fournis.
Teile ohne
Parts No.
werden nicht geliefert.
Indicates safety critical components.
L:
Scandinavia
K:
USA
P:
Canada
R:
Mexico
C:
China
I:
Malaysia
Y:
PX(Far East,Hawaii)
T:
England
E:
Europe
G:
Germany
V:
China(Shaghai)
Y:
AAFES(Europe)
X:
Australia
Q:
Russia
H:
Korea
M:
Other Areas
1 2
KRF-V6200D/KRF-V7200D
601 1A A01-3976-11 METALLIC CABINET,SILVER S
601 1A A01-3977-11 METALLIC CABINET,#3976BLAC B
603 2A
✽
A60-2510-01 PANEL,#2508-S E1X1
603 2A
✽
A60-2511-01 PANEL,#2508-B E2X2
603 2A
✽
A60-2512-01 PANEL,#2508-S E3X3
603 2A
✽
A60-2513-01 PANEL,#2508-B E4X4
604 1A
✽
A70-1720-05 REMOTE CONTROLLER ASSY
-
✽
B60-5678-00 INSTRUCTION MANUAL,EN
-
✽
B60-5679-00 INSTRUCTION MANUAL,5-LAN E
610 2A
✽
B07-2749-01 ESCUTCHEON,SILVER S
610 2A
✽
B07-2750-01 ESCUTCHEON,#2745BLAC B
611 2A B07-2747-03 ESCUTCHEON,RING-S E1X1
611 2A B07-2748-03 ESCUTCHEON,#2747BLAC E2X2
611 2A
✽
B07-2754-03 ESCUTCHEON,RING-S E3X3
611 2A
✽
B07-2755-03 ESCUTCHEON,#2754BLAC E4X4
612 2A B10-5621-02 FRONT GLASS,DISPLAY
613 2A
✽
B10-5628-03 FRONT GLASS,#5623
614 2A B11-1634-04 COLOR FILTER,PURE AUDI
615 2A B12-1408-04 INDICATOR,POWER
616 2A B12-1409-04 INDICATOR,SELECTOR
617 2A B43-0336-04 BADGE,36
✽
BLACK
620 1C E30-7330-05+ AC POWER CORD,AS ROUND PLUG X
620 1C E30-7368-05 AC POWER CORD,EN 2.5A E
621 1C E35-3943-05 FLAT CABLE,TUNER
622 1C E35-3948-05 FLAT CABLE,29P, X09-X0
623 1B,2B
✽
E35-3965-05 FLAT CABLE,27P,X14-X0
624 1C F07-2037-12 COVER,FAN
FAN 1B F09-0192-05 FAN
- J61-0307-05 WIRE BAND
630 2C J02-1464-03 FOOT
631 1B,2C J19-3751-04 UNIT HOLDER
635 1C J42-0349-05 POWER CORD BUSHING
640 2A K29-8585-04 KNOB,JOG-S S
640 2A K29-8586-04 KNOB,#8586BLAC B
641 2A K29-8444-04 KNOB,VOL-B E4X4
641 2A K29-8445-04 KNOB,VOL-S E3X3
641 2A K29-8587-03 KNOB,VOL-S E1X1
641 2A K29-8588-03 KNOB,#8587BLACK E2X2
642 2A,2B K29-8589-02 KNOB,TACT-S S
642 2A,2B K29-8590-02 KNOB,#8589BLACK B
643 2A K29-8591-03 KNOB,POWER S
643 2A K29-8592-03 KNOB,#8591BLACK B
650 2B
✽
L07-3355-05 POWER TRANSFORMER E1E2
650 2B
✽
L07-3356-05 POWER TRANSFORMER X1X2
650 2B
✽
L07-3357-05 POWER TRANSFORMER E3E4
650 2B
✽
L07-3358-05 POWER TRANSFORMER X3X4
D N82-2608-48 BINDING HEAD TAPTITE,DISPLAY
F N89-3008-48 BINDING HEAD TAPTITE SCREW
K N89-3018-48 BINDING HEAD TAPTITE SCREW
660 1A T90-0877-05 LEAD WIRE ANTENNA
661 1A T90-0893-05 LOOP ANTENNA,8T
665 1C W02-4609-05 TUNER ASSY
C11,12 CD04BJ1H100M ELECTRO 10UF 50WV
C13,14 CC73GCH1H222J CHIP C 2200PF J
C15,16 CC73GCH1H182J CHIP C 1800PF J
C17,18 CC73GCH1H100D CHIP C 10PF D
C19 CC73GCH1H470J CHIP C 47PF J
C20 CC73GCH1H101J CHIP C 100PF J
C21 CK73GB1H472K CHIP C 4700PF K
C31,32 CD04BJ1H100M ELECTRO 10UF 50WV
C33,34 CC73GCH1H821J CHIP C 820PF J
C35,36 CC73GCH1H222J CHIP C 2200PF J
C37,38 CC73GCH1H100D CHIP C 10PF D
C51,52 CD04BJ1H100M ELECTRO 10UF 50WV
C53 CC73GCH1H222J CHIP C 2200PF J
C54 CQ93FMG1H822J MYLAR 8200PF J
C55 CC73GCH1H182J CHIP C 1800PF J
C56 CQ93FMG1H822J MYLAR 8200PF J
C57,58 CC73GCH1H100D CHIP C 10PF D
C59 CC73GCH1H470J CHIP C 47PF J
C60 CC73GCH1H330J CHIP C 33PF J
C71,72 CD04BJ1H100M ELECTRO 10UF 50WV
C73,74 CC73GCH1H222J CHIP C 2200PF J
C75,76 CC73GCH1H182J CHIP C 1800PF J
C77,78 CC73GCH1H100D CHIP C 10PF D
C79,80 CK73GB1H102K CHIP C 1000PF K
C91,92 CC73GCH1H220J CHIP C 22PF J
C93,94 CC73GCH1H100D CHIP C 10PF D
C95 CK73GB1H102K CHIP C 1000PF K
C96 CC73GCH1H101J CHIP C 100PF J
C101,102 CD04BJ1H010M ELECTRO 1.0UF 50WV 6
C103,104 CC73GCH1H100D CHIP C 10PF D 6
C105,106 CD04BJ1H4R7M ELECTRO 4.7UF 50WV 6
C107,108 CC73GCH1H101J CHIP C 100PF J 6
C111 CD04BJ1H2R2M ELECTRO 2.2UF 50WV
C112 CC73GCH1H471J CHIP C 470PF J
C113 CC73GCH1H222J CHIP C 2200PF J
C114 CD04BJ1E470M ELECTRO 47UF 25WV
C115 CC73GCH1H220J CHIP C 22PF J
C116,117 CC73GCH1H101J CHIP C 100PF J
C118 CC73GCH1H182J CHIP C 1800PF J
C119,120 CC73GCH1H050C CHIP C 5.0PF C
C128 CC73GCH1H102J CHIP C 1000PF J
C131,132 CC73GCH1H101J CHIP C 100PF J 7
C133,134 CC73GCH1H100D CHIP C 10PF D 7
C135,136 CC73GCH1H330J CHIP C 33PF J 7
C153,154 CC73GCH1H100D CHIP C 10PF D
C158 CC73GCH1H100D CHIP C 10PF D
C161,162 CK73GB1E154K CHIP C 0.15UF K
C163,164 CK73GB1H473K CHIP C 0.047UF K
C165,166 CK73GB1H223K CHIP C 0.022UF K
C171,172 CC73GCH1H101J CHIP C 100PF J 6
C173,174 CC73GCH1H100D CHIP C 10PF D 6
C175,176 CC73GCH1H330J CHIP C 33PF J 6
SURROUND (X08-3492-70&-71)

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Kenwood KRF-V6200D and is the answer not in the manual?

Kenwood KRF-V6200D Specifications

KRF-V7200D

General IconGeneral
Rated output power during STEREO operation100 W + 100 W
Effective output power during STEREO operation RMS120 W + 120 W
Effective power output during SURROUND operation FRONT100 W + 100 W
CENTER100 W
SURROUND100 W + 100 W
SURROUND BACK100 W + 100 W
Total harmonic distortion0.02 %
Frequency response20 Hz – 80 kHz, +0 dB – –3.0 dB
Signal to noise ratio100 dB
Input sensitivity / impedance550 mV / 40 kΩ
Output level / impedance550 mV / 470 Ω
Tone control BASS±10 dB (at 100 Hz)
TREBLE±10 dB (at 10 kHz)
Sampling frequency32 kHz, 44.1 kHz, 48 kHz, 96 kHz
Input level / wave length Optical–15 dBm – –21 dBm / 660 nm ±30 nm
Input level / impedance Coaxial0.5 Vp-p / 75 Ω
VIDEO inputs / impedance Composite1 Vp-p / 75 Ω
VIDEO outputs / impedance Composite1 Vp-p / 75 Ω
S-VIDEO inputs / impedance Y-singal1 Vp-p / 75 Ω
C-singal0.286 Vp-p / 75 Ω
COMPONENT VIDEO inputs/ impedance Y-signal1 Vp-p / 75 Ω
CB/ CR-signal0.7 Vp-p / 75 Ω, 0.7 Vp-p / 75 Ω
COMPONENT VIDEO outputs/ impedance Y-signal1 Vp-p / 75 Ω
Tuning frequency range87.5 MHz – 108.0 MHz
Usable sensitivity MONO1.3 µV / 13.2 dBf
STEREO45 µV / 42.1 dBf, 0.8%, 60 dB
Total harmonic distortion MONO0.2%
Signal to noise ratio MONO65 dB
Stereo separation36 dB
Selectivity64 dB
Frequency response+0.5 dB, –3.0 dB
Tuning frequency range531 kHz – 1, 602 kHz
Usable sensitivity16 µV / (600 µV/m)
Signal to noise ratio50 dB
Usable USB deviceUSB Mass Storage Class
InterfaceUSB 1.1 (Full speed) compatible
Maxmum current drain500 mA
Power consumption240 W
Standby power consumptionless than 0.6 W
DimensionsW: 440 mm (17-5/16") H: 159 mm (6-1/4") D: 345 mm (13-9/16")
Weight9.6 kg (21.2 lb)

KRF-V6200D

General IconGeneral
Rated output power during STEREO operation100 W + 100 W
Effective output power during STEREO operation RMS120 W + 120 W
Effective power output during SURROUND operation FRONT100 W + 100 W
CENTER100 W
SURROUND100 W + 100 W
Total harmonic distortion0.05 %
Frequency response20 Hz – 70 kHz, +0 dB – –3.0 dB
Signal to noise ratio100 dB
Input sensitivity / impedance550 mV / 40 kΩ
Output level / impedance550 mV / 470 Ω
Tone control BASS±10 dB (at 100 Hz)
TREBLE±10 dB (at 10 kHz)
Sampling frequency32 kHz, 44.1 kHz, 48 kHz, 96 kHz
Input level / wave length Optical–15 dBm – –21 dBm / 660 nm ±30 nm
Input level / impedance Coaxial0.5 Vp-p / 75 Ω
VIDEO inputs / impedance Composite1 Vp-p / 75 Ω
VIDEO outputs / impedance Composite1 Vp-p / 75 Ω
S-VIDEO inputs / impedance Y-singal1 Vp-p / 75 Ω
C-singal0.286 Vp-p / 75 Ω
COMPONENT VIDEO inputs/ impedance Y-signal1 Vp-p / 75 Ω
CB/ CR-signal0.7 Vp-p / 75 Ω, 0.7 Vp-p / 75 Ω
COMPONENT VIDEO outputs/ impedance Y-signal1 Vp-p / 75 Ω
Tuning frequency range87.5 MHz – 108.0 MHz
Usable sensitivity MONO1.3 µV / 13.2 dBf
STEREO45 µV / 42.1 dBf, 0.8%, 60 dB
Total harmonic distortion MONO0.2%
Signal to noise ratio MONO65 dB
Stereo separation36 dB
Selectivity64 dB
Frequency response+0.5 dB, –3.0 dB
Tuning frequency range531 kHz – 1, 602 kHz
Usable sensitivity16 µV / (600 µV/m)
Signal to noise ratio50 dB
Usable USB deviceUSB Mass Storage Class
InterfaceUSB 1.1 (Full speed) compatible
Maxmum current drain500 mA
Power consumption250 W
Standby power consumptionless than 0.6 W
DimensionsW: 440 mm (17-5/16") H: 159 mm (6-1/4") D: 345 mm (13-9/16")
Weight8.3 kg (18.3 lb)
