8
INSTALLING THE SPEAKER/ MICROPHONE OR HEADSET
Note:
◆ The transceiver is not fully water resistant when using a speaker/ microphone
or headset.
◆ Use the Phillips #1 screwdriver.
1 Insert the speaker/ microphone plugs into the
speaker/ microphone jacks of the transceiver.
2 Place the locking bracket over the speaker/
microphone plugs so that the locking tabs insert
into the transceiver grooves.
3 Secure the locking bracket in place using the
attached screw.
Speaker/ microphone
locking bracket
Screw
To Next Page
