4
Press [J]/[K] to select a function item.
●
On full key models, you can enter a function number directly. Refer to “CHARACTER
ENTRY” {p. 19} .
5
Press the [ ] or [ ] key to set up the selected function item.
●
Press [
] or [#] to return to the category list.
6
Press [J]/[K] to select your desired setting.
●
For settings with more than one level, repeat steps 5 and 6.
7
Press the [
] or [ ] key to set the selected setting and exit Menu mode.
●
Press [ ] or [#] at any time to return to the previous display.
●
Press [
] at any time to exit Menu mode.
KEY MODE
Your transceiver operations vary according to the functions that your dealer has
programmed onto the transceiver keys. Refer to “FUNCTION LIST” {p. 14} for the
available programmable functions.
FUNCTION LIST
PF Key: Functions that can be programmed to the transceiver keys
Menu: Functions that can be accessed using the transceiver Menu
Analog Conv.: Channels set up for Analog Conventional Operation
NXDN Conv.: Channels set up for NXDN Conventional Operation
P25 Conv.: Channels set up for P25 Conventional Operation
NXDN Trunking: Channels set up for NXDN Trunking Operation
P25 Trunking: Channels set up for P25 Trunking Operation
p
: Available
N/A: Not Available
Function
Menu
Display
PF Key
Menu
Analog
Conv.
NXDN
Conv.
P25
Conv.
NXDN
Trunking
P25
Trunking
None -
p
N/A
p p p p p
Activity Detection Activity Det
p p p p p p p
Activity Reset -
p
N/A
p p p p p
ANR Preset ANR Preset N/A
p p p p p p
Audio Profile Audio Profile N/A
p p p p p p
Autodial Auto Dial
p p
N/A N/A N/A N/A
p
AUX AUX
p p p p p p p
14

Kenwood NX-5200 Specifications

General

IP Rating	IP67
Zones	128
GPS	Yes
Bluetooth	Yes
Voltage Range	7.5V DC ±20%
Operating Temperature	-30°C to +60°C
Frequency Range	136-174 MHz
Battery Life	14 hours (Digital mode)
Digital Protocol	NXDN, DMR
Display	LCD
