3
Press and hold the PTT switch to make the call.
●
Speak into the transceiver as you would during a normal call.
●
The LCD display will return to the zone and channel screen after call ends.
o
Making Group Calls (P25 Trunking)
You can select a channel with the Talkgroup ID you wanted to call to make a call to
those parties on a Trunking channel.
●
If the traffic channel is busy, a busy message appears and the busy tone sounds. Release
the PTT switch and wait for the channel to become free. When the traffic channel becomes
free, a proceed tone sounds.
1
Select the configured Talkgroup channel using the keys programmed as
[Channel Up]/ [Channel Down].
2
Press and hold the PTT switch to make the call.
●
Speak into the transceiver as you would during a normal call.
●
The display will alternate between the called Group ID/ name and “Calling”.
●
The LCD display will return to the zone and channel screen after call ends.
o
Making Individual Calls (P25 Trunking)
You can make calls to specific persons on a Trunking channel.
1
Press the key programmed as [Individual] or [Individual + Status] to enter
Individual Call Mode.
Alternatively, press the key programmed as [Menu] to enter Individual Call Mode using
the Menu Mode.
7

Kenwood NX-5200 Specifications

General

IP Rating	IP67
Zones	128
GPS	Yes
Bluetooth	Yes
Voltage Range	7.5V DC ±20%
Operating Temperature	-30°C to +60°C
Frequency Range	136-174 MHz
Battery Life	14 hours (Digital mode)
Digital Protocol	NXDN, DMR
Display	LCD
