Kenwood NX-5200 User Manual

2
Press the [J] and [K] keys to select a unit ID from the list that has been pre-
entered into your transceiver.
●
The target unit ID/ name appears on the display.
Alternatively, on full key models, you can enter a unit ID directly by pressing the keypad.
●
Press the [
] key to enter the manual input mode. Refer to “CHARACTER
ENTRY” {p. 19} .
Press the [
] key to confirm the code after entering the code using the keypad.
To delete the code entered, press the [ ] key to delete one digit, or press and hold
the [
] key to delete all digits.
3
Press and hold the PTT switch to make the call.
●
Speak into the transceiver as you would during a normal call.
●
The display will alternate between the called unit ID/ name and “Calling”.
●
The LCD display will return to the zone and channel screen after call ends.
4
To end the call, press the key programmed as [Clear].
o
Making Group Calls (NXDN Conventional)
You can select a group ID from the list to make a call to those parties on a
Conventional channel.
1
Press the key programmed as [Group], [Group + Short Message] or [Group
+ Status] to enter Group Call Mode.
Alternatively, press the key programmed as [Menu] to enter Group Call Mode using the
Menu Mode.
●
The group ID list appears on the display.
8

Kenwood NX-5200 Specifications

General

IP Rating	IP67
Zones	128
GPS	Yes
Bluetooth	Yes
Voltage Range	7.5V DC ±20%
Operating Temperature	-30°C to +60°C
Frequency Range	136-174 MHz
Battery Life	14 hours (Digital mode)
Digital Protocol	NXDN, DMR
Display	LCD
