(No.RA094<Rev.002>)1-5
EN measurement compliant (E2 type only)
Specifications are measured according to applicable standards. Specifications shown are typical.
JVCKENWOOD Corporation reserves the right to change specifications without prior notice or obligation.
GENERAL
Frequency Range 400 ~ 470 MHz
Channel Capacity 32
Channel Spacing Analog 12.5 / 20 / 25 kHz
Digital 6.25 / 12.5 kHz
PLL Channel Step 3.125 / 5 / 6.25 kHz
Frequency Stability ± 0.5 ppm
Power Supply 10.8 ~ 15.6 V DC
Current Drain Standby 0.7 A
Transmitting 12.0 A (Max. power), 9.0 A (25 W)
Operating Temperature -30 C to +60 C
Antenna Impedance 50
Dimensions (W x H x D) Projections included 214.5 x 44.0 x 242.9 mm
Projections not included 208.5 x 44.0 x 211.5 mm
Weight (net) 1.9 kg
RECEIVER
Sensitivity DMR (5 % BER) -7 dBV (0.22 V)
DMR (1 % BER) -5 dBV (0.28 V)
NXDN (3 % BER) 6.25 / 12.5 kHz -8 dBV (0.20 V) / -6 dBV (0.25 V)
NXDN (1 % BER) 6.25 / 12.5 kHz -7 dBV (0.22 V) / -5 dBV (0.28 V)
Analog (20 dB SINAD) -3 dBV (0.35 V)
Selectivity Analog 12.5 / 20 / 25 kHz 72 / 76 / 78 dB
FM Hum & Noise Analog 12.5 / 20 / 25 kHz 50 / 53 / 55 dB
Intermodulation 72 dB
Spurious Rejection 85 dB
TRANSMITTER
RF Output Power 40 ~ 1 W (40 W @ 50% Duty, 25 W @ 100 % Duty)
Spurious Emission -36 dBm
1 GHz, -30 dBm > 1 GHz
FM Hum & Noise Analog 12.5 / 20 / 25 kHz 50 / 53 / 55 dB
Audio Distortion 1 %
Emission Designator 16K0F3E, 14K0F2D, 14K0F3E, 12K0F2D, 8K50F3E,
7K50F2D, 8K30F1E, 8K30F1D, 8K30F7W, 7K60FXE,
7K60FXD, 7K60FXW, 7K60F7E, 7K60F7D, 7K60F7W,
4K00F1E, 4K00F1D, 4K00F7W, 4K00F2D
