Kenwood TM-V71A Service Manual

TM-V71A/V71E
2
Document Copyrights
Copyright 2007 by Kenwood Corporation. All rights
reserved.
No part of this manual may be reproduced, translated,
distributed, or transmitted in any form or by any means,
electronic, mechanical, photocopying, recording, or
otherwise, for any purpose without the prior written
permission of Kenwood.
Disclaimer
While every precaution has been taken in the preparation
of this manual, Kenwood assumes no responsibility for
errors or omissions. Neither is any liability assumed for
damages resulting from the use of the information contained
herein. Kenwood reserves the right to make changes to any
products herein at any time for improvement purposes.
DISASSEMBLY FOR REPAIR
Precautions for Disassembly
When removing the rear case from the panel, open the
bottom side slowly so as not to stress the FPC, as the FPC
on the rear case is connected with the connector of the
display PCB.
Display PCB
FPC
Panel
Rear case

Kenwood TM-V71A Specifications

General

Input voltage	13.8 V
Microphone included	Yes
Product type	Car CB radio
Product color	Black
Housing material	-
Frequency range	45.05 - 455000 MHz
Channels quantity	1000 channels

Weight and Dimensions

Depth	213.1 mm
Width	140 mm
Height	43 mm
