Kenwood VR-606 VR-616 User Manual

30
EN
Basic remote control operations for other components
Setup code chart
Manufacturer Setup Codes
GE 102
HITACHI 114, 115
JVC 113
LOEWE 123, 124
MAGNAVOX 109
MITSUBISHI 121
PANASONIC 111, 112, 122
PHILIPS 109
PIONEER 116
PROSCAN 117
QUASAR 118
RCA 102, 103, 104, 105, 106
SAMSUNG 109
SANYO 119
SHARP 110
SONY 101
TOSHIBA 120
ZENITH 107, 108
Cable tuner (CBL) Setup codes DVD player Setup code
Manufacturer Setup Codes
JVC 801
KENWOOD 805, 808
PANASONIC 804
PHILIPS 807
PIONEER 803
SONY 802
TOSHIBA 806
TV Setup codes VCR Setup codes
Manufacturer Setup Codes
G.I. 209
GEMINI 218
HAMLIN 210, 211
JERROLD 201, 202
MACOM 215, 216, 217
OAK 212, 213, 214
PANASONIC 221, 222
PHILIPS 219, 220
PIONEER 206, 207
S. ATLANTA 203
SAMSUNG 223
TOCOM 208
ZENITH 204, 205
Manufacturer Setup Codes
GE 307, 321
GOLD STAR 323
HITACHI 307, 308, 328, 329
JVC 324, 325, 326, 327
MAGNAVOX 311, 312, 313
MITSUBISHI 315, 316, 317, 318
PANASONIC 309, 310
PHILIPS 313
RCA 308
SANYO 330
SHARP 319, 320
SONY 301, 302, 303, 304, 305, 306
TOSHIBA 314, 331
ZENITH 322
DSS/SAT audio service Setup codes
Manufacturer Setup Codes
ECHOSTAR 903
G.I. 902
HITACHI 908
HUGHES 906
PANASONIC 905
PRIMESTAR 909
RCA 901
SONY 907
TOSHIBA 904
*5228/30-36/EN 14/06/2002, 12:05 PM30

Kenwood VR-606 VR-616 Specifications

Audio Performance

rated power output during stereo operation	100 watts per channel
effective power output during surround operation (front)	100 W + 100 W
effective power output during surround operation (center)	100 W
effective power output during surround operation (surround)	100 W + 100 W
effective power output during surround operation (subwoofer)	100 W

Audio Characteristics

total harmonic distortion	0.05% (1 kHz, 50 W, 8Ω)
frequency response (CD)	20 Hz ~ 70 kHz, +0 dB, –3.0 dB
signal to noise ratio (CD)	95 dB
input sensitivity / impedance (CD)	550 mV / 47 kΩ
input sensitivity / impedance (DVD/6CH INPUT)	550 mV / 47 kΩ

Digital Audio

sampling frequency	32 kHz, 44.1 kHz, 48 kHz, 96 kHz
input level / impedance / wave length (optical)	(–15 dBm ~ –21 dBm), 660 nm ±30 nm
input level / impedance (coaxial)	0.5 Vp-p / 75 Ω

Video

video inputs / outputs	1 Vp-p / 75 Ω
s video inputs / outputs (luminance signal)	1 Vp-p / 75 Ω
s video inputs / outputs (chrominance signal)	0.286 Vp-p / 75 Ω

FM Tuner

tuning frequency range	87.5 MHz ~ 108.0 MHz
usable sensitivity (MONO)	1.3 µV (75 Ω)/ 13.2 dBf (75 kHz DEV., SINAD 30 dB)
50dB quieting sensitivity (STEREO)	28 µV (75 Ω)/ 40.2 dBf
total harmonic distortion (MONO)	0.5% (71.2 dBf input)
total harmonic distortion (STEREO)	0.7% (71.2 dBf input)

AM Tuner

tuning frequency range (10 kHz step)	530 kHz ~ 1, 700 kHz
usable sensitivity (30% mod., S/N 20dB)	16 µV / (600 µV/m)
signal to noise ratio (30% mod. 1 mV input)	50 dB

General

power consumption	2.2 A
ac outlet (switched)	(total 150 W, 1.25 A max.)
dimensions (W x H x D)	440 mm x 143 mm x 303 mm
weight (net)	7.7 kg (17.00 lb)
