XD-980MD (En)
33
Preparation section Basic section Application section Knowledge sections
Playback of CD
Select the RANDOM mode.
If the “PGM” indicator is lit, press the
P.MODE key to turn it off.
÷Playback stops after each title has been played once.
÷The random playback can also be repeated by pressing the
REPEAT key.
÷Pressing the 4 key once returns to the
beginning of the track being played.
÷The “RANDOM” indicator goes off and the playback in order
of the tracks starts from the track being played.
To select another track in the middle of playing one To cancel random playback
Press so that the “RANDOM” indicator goes off.
Select the “CD” input.
Listening to an unexpected title sequence
(random playback)
As the titles each time are selected randomly, the music
can be enjoyed without getting tired of it.
Confirm that the “PGM” indicator is not lit.
1
2
Each press switches the modes as follows.
1 INTRO ...................... There is no random playback
with this selection.
2 DISC RANDOM....... Random play of one disc.
3 ALL RANDOM ........ Random play of all discs.
4 Normal playback
P. CALL
Confirm that this is not lit.
P. MODE
RANDOM
CD)1
@
)))
EX
.
BASS
:
123
EQ.
CLASSIC
MANUAL
POPROCK
VOL.
6
7
2
3
4
5
PGM
Please select the disc before selecting
“DISC RANDOM”.
RANDOM
123
RUNNING
EQ.
CLASSIC
MANUAL
POPROCK
VOL.
RANDOM
ALL
6
8
2
4
123
RUNNING
EQ.
CLASSIC
MANUAL
POPROCK
VOL.
RANDOM
DISC
6
8
2
4
For random playback of one disc For random playback of all discs

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Kenwood XD-980MD and is the answer not in the manual?

Kenwood XD-980MD Specifications

Main unit (RXD-980MD)

Amplifier Section IconAmplifier Section
rated power output50 watts per channel minimum RMS at 6 Ω, 1 kHz
signal to noise ratio85 dB (AUX)
input sensitivity / impedanceAUX: 200 mV / 30 kΩ, MIC 1, 2: 3.0 mV / 22 kΩ
Tuner Section IconTuner Section
FM tuning frequency range87.5 MHz ~ 108 MHz
MW (AM) tuning frequency range531 kHz ~ 1, 602 kHz
LW tuning frequency range153 kHz ~ 279 kHz
MD Recorder Section IconMD Recorder Section
systemMinidisc digital audio system
recording methodField modulation overwrite method
playing rotationApprox. 400 rpm ~ 900 rpm (CLV)
General IconGeneral
power consumption120 W
dimensionsW: 270 mm, H: 330 mm, D: 357 mm
weight (net)9.1 kg (20 lb)

Speakers (LS-N750)

Speaker Configuration IconSpeaker Configuration
woofer180 mm, cone type
tweeter65 mm, cone type
super-tweeter25 mm, dome type
General IconGeneral
impedance6 Ω
maximum input level100 W
dimensionsW: 220 mm, H: 330 mm, D: 316 mm
