KERN CDS Series Operating Instruction

6 CKE-BA-e-2132
KERN CKE 36K0.1 CKE 65K0.2
Product number / type TCKE 36K-4-A TCKE 65K-4-A
Interval (d)
0.1 g 0.2 g
Weighing range (Max)
36,000 g 65,000 g
Tare range
(subtractive)
36,000 g 65,000 g
Reproducibility 0.2 g 0.4 g
Linearity ±0,5 g ±1,0 g
Settling time (standard) 3 s
Minimum part weight when
counting the number of pieces in
laboratory conditions*
0.1 g 0.2 g
Minimum part weight when
counting the number of pieces in
standard conditions*
1 g 2 g
Adjustment points 10/20/30/36 kg 20/30/50/60 kg
Recommended adjustment
weight F1
(not delivered)
20 kg + 10 kg 50 kg
Heating time 2 h 4 h
Weight units g, kg, lb, gn, dwt, oz, ozt
Air humidity max. 80%, relative (non-condensing)
Permissible ambient temperature +10°C ... +40°C
Input voltage
of the device
9 V, 300 mA
Input voltage of
the power supply
110–240 VAC; 50/60 Hz
Batteries (option) 6 pcs., 1.5 V, type AA
Rechargeable battery operation
(option)
operating time 90 h (illumination off)
operating time 40 h (illumination on)
charging time ca. 10 h
Automatic switch-off (batteries) 3 min
Automatic switch-off (mains) the choice of: 1, 2, 3, 5, 30 min
Housing dimensions
(W × D × H) [mm]
350 × 390 × 120
Scales plate,
stainless steel [mm]
340 × 240
Net weight [kg] 6.5
Interfaces
• RS-232 (DB9 port), standard equipment
• 'USB Device' (USB B) port, factory option
Equipment for the under-scales
weighing hanger
yes (hook included)
