KERN CDS Series Operating Instruction

CKE-BA-e-2132 7
Small housing:
KERN CKE 360-3 CKE 3600-2
Product number / type
TCKE 300-3-A
TCKE 3000-2-A
Interval (d)
0,001 g 0,01 g
Weighing range (
Max
)
360 g 3600 g
Tare range
(subtractive)
360 g 3600 g
Reproducibility 0,001 g 0,01 g
Linearity ±0,005 g ±0,03 g
Settling time (standard) 3 s
Minimum part weight when
counting the number of pieces in
laboratory conditions*
2 mg 20 mg
Minimum part weight when
counting the number of pieces in
standard conditions*
20 mg 200 mg
Adjustment points
100/150/200/300/350 g 1/1,5/2/3/3,5 kg
Recommended adjustment
weight F1
(not delivered)
300 g 3 kg
Heating time 2 h 2 h
Weight units g, kg, lb, gn, dwt, oz, ozt, free
Air humidity
max. 80%, relative (non-condensing)
Permissible ambient temperature +5 °C ... + 35 °C
Input voltage
of the device
6 V, 1 A
Input voltage of
the power supply
100V – 240V AC, 50/60 Hz
Batteries (option)
4 x 1,5V Type AA
Rechargeable battery operation
(option)
operating time 48 h (illumination off)
operating time 24 h (illumination on)
charging time ca. 8 h
Automatic switch-off (batteries) off, 30s, 1,2,5,30, 60 min
Housing dimensions
(W × D × H) [mm]
245 x 165 x 80
Scales plate,
stainless steel [mm]
Ø 81 rectangular 130 x 130
Net weight [kg]
0,9
1,5
Interfaces
• KUP
• RS-232, option
• 'USB Device' port, option
• WLAN option
Equipment for the under-scales
weighing hanger
yes (hook included)
