KERN FKB A Series User Manual

TFKB_B-BA-e-2210 5
1 Technical data
KERN
FKB 6K0.02
FKB 8K0.1
FKB 8K0.05
FKB 15K0.5A
Item no./ Type
TFKB 6K-5-B
TFKB 8K-4-B
TFKB 8K-5-B
TFKB 15K-4-B
Readability (d)
0.02 g
0.1 g
0.05 g
0.5 g
Weighing range (max)
6.000 g
8.000 g
8.000 g
15.000 g
Taring range (subtractive)
6.000 g
8.000 g
8.000 g
15.000 g
Reproducibility
0.04 g
0.1 g
0.05 g
0.5 g
Linearity
± 0.1 g
± 0.3 g
± 0.15 g
± 1.5 g
Stabilization time (typical)
3 sec.
Smallest part weight for
piece counting - under lab
conditions*
20 mg
100 mg
50 mg
1 g
Smallest part weight for
piece counting - under
normal conditions**
200 mg
1 g
500 m
10 g
Adjustment points
2 / 4 / 6 kg
2 / 5 / 8 kg
2 / 5 / 8 kg
5 / 10 / 15 kg
Recommended
adjustment weight (not
supplied)
5 kg; 1 kg (F1)
5 kg; 2 kg; 1 kg
(F1)
5 kg; 2 kg; 1 kg
(F1)
15 kg (F2)
Warm-up time
2 hrs.
Weighing Units
kg, g, gn, dwt, ozt, lb, oz, FFA
Humidity of air
max. 80% rel. (non-condensing)
Allowable ambient
temperature
-10 °C ... + 40 °C
Input voltage Appliance
6 V, 1 A
Input voltage Mains
adapter
100 V - 240V AC 50 / 60Hz
Batteries (option)
4 x 1.5V AA
Rechargeable battery
operation (optional)
Operating time 48 hrs (backlight off)
Operating time 24 hrs (backlight on)
Loading time approx. 8 hrs.
Auto-Off (battery,
rechargeable battery)
selectable off, 30s, 1, 2, 5, 30, 60 min
Dimensions housing
350 x 390 x 120 (W x D x H) [mm]
Weighing plate, stainless
steel
340 x 240 (B x T) [mm]
Net weight
6 kg
Interfaces
RS-232 (optional), Ethernet (optional), Bluetooth BLE (v4.0) (optional),
USB-Device (optional), WLAN (optional) via KUP
Underfloor weighing
device
yes (hook supplied)
