572/573/KB/DS/FKB-BA-defsi-0651
41
7.4.2 Description of the data transfer
Structure of each data transfer:
Without Numerator:
Bit-Nr. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18
B B B B B B B B 0
.
0 B g B B CR LF
B*
B*: = Blank or % in the range of zero point.
B, 0,
.
, g: = Blank or weighing value with unit, depending on the load on the weighing plate.
CR: = Carriage Return
LF: = Line Feed
With Enumerator:
Bit.Nr. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
N N N B* B B B B B B B 0
.
0 B G B B CR LF
N: = Enumerator
7.4.3 Numerator
The Numerator is found under the menu point “Printer” and can be activated and deactivated. When editing
data with the use of the print option, the range of the numerator will increase by one place.
7.5 Printer
With the serial data output RS 232 a printer can be connected.
The printout shows the weight in grams. When the counting mode is selected the number of pieces or the
weight is printed. When the percent mode is selected, the percentage or the weight will be printed. Press
The PRINT-key to print weighing results. Select the enumerator to number the weighing continuously. Turn
off the balance or use the CLEAR function to Reset the enumerator to (000).
7.6 Underfloor weighing
Objects which, because of their size or shape, cannot be put on the scale, can be weighed by means of un-
derfloor weighing.
Proceed as follows:
• Switch off the balance.
• Turn the balance over,
without loading the balance plate.
• Open the cover plate on the base of the balance.
• Hang on the hook for underfloor weighing .
• Place the balance over an opening.
• Hang the item to be weighed on the hook and carry out weighing.
! CAUTION !
Take care that the hooks used for the underfloor weighing are stable enough to hold the goods
which you wish to weigh (risk of breakage).
Always make sure that there are no living beings or materials below the load that could be injured or
damaged.
! NOTE !
After completing the underfloor weighing, the opening in the floor of the balance must be closed
again (dust protection).
