ELECTRICAL CONNECTION
WATER INLET HOSE CONNECTION
• YourWashingMachinerequiresa220-240V,50Hzmainssupply.
• Themainscordofyourwashingmachineisequippedwithan
earthedplug.Thisplugshouldalwaysbeinsertedtoanearthed
socketof10amps.
• Ifyoudonothaveasuitablesocketandfuseconformingwiththis,
pleaseensuretheworkiscarriedoutbyaqualifiedelectrician.
• Wedonottakeresponsibilityfordamagethatoccursduetotheuseofungrounded
equipment.
NOTE:
Operatingyourmachinewithlowvoltagewillcausethelifecycleofyourmachinetobe
reducedanditsperformancetoberestricted.
• Yourmachinemayhaveeitherasinglewaterinletconnection
(cold)ordoublewaterinletconnection(hotandcold)depending
onthemachinespecifications.Thewhitecappedhoseshould
beconnectedtocoldwaterinletandredcappedhosetothehot
waterinlet(ifapplicable).
• Topreventwaterleaksatthejoints,either1or2nuts(depending
onyourmachine’sspecifications)aresuppliedinthepackaging
withthehose.Fitthesenutstotheend(s)ofthewaterinlethose
thatconnecttothewatersupply.
• Connectnewwaterinlethosestoa¾˝,threadedtap.
• Connectthewhitecappedendofthewaterinlethosetothe
white water inlet valve on the rear side of the machine and
the red capped end of the hose to the red water inlet valve
(ifapplicable).
• Handtightentheconnections.Ifinanydoubt,consultaqualified
plumber.
• Waterflowwithpressureof0.1-1Mpawillallowyourmachine
tooperateatoptimumefficiency(pressureof0.1Mpameans
thatmorethan8litresofwaterperminutewillflowthrough
afullyopenedtap).
3/4”
10 mm
