Chamber
Information / chamber type Values
Weight 16 kg
Inlet [DN]
100 / 150
Must be drilled on-site
Pressure connection [DN] 50 (d=63 mm) for PVC
Conduit pipe Must be drilled on-site
Aeration/ventilation Must be drilled on-site
Height 830 mm
Outside diameter 600 mm
Cover plate / version Can bear loads up to 300 kg
Mono 25 l
Mono Tronic 60 l
Pumping
volume
Duo Tronic 60 l
Switch-on height 80 mm / 160 mm
EN
016-102_01 DE_EN_FR Pumping station / Installation and operating manual 63 / 144
