Kessel Aqualift F Basic - Technical Data

EN
4 Technical data
4.1 Technical data
Pump
Information / pump type STF 1300
Weight 10 kg
Power P1 / P2 1.3 kW / 0.8 kW
Speed 2650 rpm
Operating voltage 230 V; 50 Hz
Rated current 6.0 A
Max. pumping capacity 21 m³/h
Max. pumping height 10 m
Max. temperature
Pumping medium
35°C
Protective rating IP68 (3m)
Protection class I
Motor protection integrated
Connection type (Mono) Schuko earthing pin plug
Connection type (Duo) Directly wired to the control unit
Connection cable 10 m; 3 x 1.0 mm²
Recommended circuit breaker C16 A
Performance and pumping height of the pump
2
4
6
8
10
4
6
2
8 10 12
16 1814
20 22
Q
[
m
3
/h
]
H
[
m
]
STF 1300
62 / 144 Pumping station / Installation and operating manual 016-102_01 DE_EN_FR
