Kessel Aqualift F Basic - Page 65

5.2 Deeper installation
For larger installation depths, the optional extension section
Art. no. 829100 can be used.
Lay seal in the chamber, correctly positioned.
Insert the extension section into the chamber and level
with ground.
140 - 440 mm
1
2
EN
016-102_01 DE_EN_FR Pumping station / Installation and operating manual 65 / 144
