Einbau- und Betriebsanleitung22 016-059
4.7 Abdeckplatte montieren
Dichtung ggf. einfetten.
Ggf. Schlüssel einführen und Lock & Lift durch Linksdrehung entriegeln.
Abdeckplatte wie abgebildet hineinführen.
Abdeckplatte durch Rechtsdrehung des Schlüssels verriegeln.
Abdeckplatte ist montiert.
1
3
2
Abb. [17]
