Installation and operating manual32 016-059
1. Notes on this manual
The following conventions make it easier to navigate the manual:
Symbol Explanation
[1] See Figure 1
(5)
Position number 5 from the adjacent
figure
➊➋➌➍➎➏➐➑➒➓
Action step in figure
1 Check whether manual
control has been activated.
Prerequisite for action
 Press OK. Action step
✓ System is ready for
operation.
Result of action
➲ Chapter "2. Safety"
Cross-reference to Chapter 2
||Dene maintenance
interval|
Screen text
Bold type
Particularly important or safety-relevant
information
Italics
Variants or additional information (e.g.
applicable only for ATEX variants)
L
Technical information or instructions
which must be paid particular attention.
2. Safety
The following symbols are used:
Icon Meaning
Isolate device!
Observe the instructions for use
CE marking
Warning, electricity
WEEE icon, product governed by RoHS Guideline
WARNING
Warns of a hazard for persons. Ignoring this warning can
lead to serious injuries or death.
CAUTION
Warns of a hazard for persons and material. Ignoring this
warning can lead to serious injuries and material damage.
