Kessel Aqualift S Compact - Product Technical Specifications

Installation and operating manual 37 016-059
3. Technical data
Pump
GTF 500
GTF 500 resistant
Mono/Duo
GTF 1200
Mono/Duo
Weight (system) 19.9 / 22.8kg 24.9 / 35.7kg
Power P1 / P2 500 / 360 W 1400 / 840 W
Speed 2800 rpm 2650 rpm
Operating voltage 230 V / 50 Hz 230 V / 50 Hz
Rated current 2.5 A per pump 6.2 A per pump
Max. pumping capacity 10 m/h 15 m/h
Max. pumping height 8 m 9 m
Completely free passage 10 mm 30 mm
Max. temperature
Pumping medium
35 °C 35 °C
Protective rating IP 68 (3m) IP 68 (3m)
Protection class I I
Motor protection integrated integrated
Connection type Earthed coupling/control unit Earthed coupling/control unit
Recommended fuse C16A C16A
Operating mode S1 S1
Load class K3/L15
Inlet DN100
Resistance to groundwater 3 m
