Assemblies and functional units
(1)
Pump tank
(2)
Protective tube for alarm probe (only Tronic variants)
(3)
Alarm probe (only Tronic variants)
(4)
Pressure sensor (only Tronic variants)
(5)
Control unit (only Tronic variants)
(6)
Upper section
(7)
Flap housing with backflow preventer
(8)
Pump(s)
(9)
Connection nozzle (conduit pipe)
Fig. [4]
1
2
4
5
6
7
9
8
3
